Input

Network Video Input 32-CH

Bandwidth Requirement 256Mbps or 200Mbps(When RAID is enabled) (Incoming)

256Mbps or 200Mbps(When RAID is enabled) (Outgoing)



Output

HDMI Output 2-CH, Resolution: 3840x2160/60Hz(HDMI1 Only), 3840x2160/30Hz(HDMI1 Only), 1920x1080/60Hz, 1920x1080/50Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz. (HDMI supports Audio Output)

VGA Output 2-CH, Resolution: 1920x1080/60Hz, 1920x1080/50Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz.

Dual Stream Support

Recording Resolution 12MP/8MP/6MP/5MP/4MP/3MP/1080P/ UXGA/720P/D1/VGA/CIF/QCIF

Synchronous Playback 4*(30fps @8MP), 5*(30fps@6MP), 6*(30fps@5MP), 8*(30fps @4MP), 10*(30fps @3MP), 16*(30fps @1080P), 32*(30fps @720P)



Format

Video Compression H.265+/H.265(HEVC)/H.264+/H.264

Audio Format G.711/AAC/G.722/G.726



Storage

SATA 8*SATA HDD (3.5”)

eSATA 1*eSATA

Capacity Up to 10TB capacity for each HDD

Disk Array

Array Type RAID0, RAID1, RAID5, RAID6, RAID10



Record

Recording Type Continuous, Event (Motion Detection, Alarm, VCA, Smart Analysis)

Snapshot Type Continuous, Event (Motion Detection, Alarm, VCA, Smart Analysis)

Playback Type General Playback, Event Playback, Tag Playback, Split Playback, Picture Playback

BackupVideo backup, Image Backup



Network

Network Protocols IPv4/IPv6, TCP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, DNS, DDNS, DHCP, NTP, SNTP, SMTP, SNMP, UPnP, NFS



Interface

Network Interface 2*RJ45 10/100/1000Mbps

USB Interface 1*USB 3.0; 2*USB 2.0

Serial Interface 1*RS-485 Series Port for PTZ, 1*RS-232 Series Port for Console, 1*RS-485 Series Port for Keyboard

Audio Input/Output 1*RCA/2*RCA

Alarm Input 16-CH

Alarm Output 4-CH



General

Compatibility ONVIF

Advanced Function ANR, N+1 Hot Spare

Warranty 3/5 Years
