Smart Stream (Bandwith, storage, and bit rate save with Smart Stream ON, eg H.265+ save 70%~80% bandwith of H.264)

Powerfull IR LEDs (Equipped with 3rd generation dot matrix IR LEDs, guarenteeing excellent image quality, long lifespan and energy efficiency)

Model

Camera Name : Milesight MS-5364-PB 5MP H.265 Vandal Proof Mini Bullet Network Camera

Image Sensor : 1/2.8" Progressive Scan CMOS

Min. Illumination : Color: 0.005Lux @F1.2, B/W: 0Lux with IR on

WDR : 120db Super WDR

Lens : 2.8mm @F2.0 (*optional: 3.6mm @F2.2/ 6.6MM @F1.6)

Mount : Φ12

Field of View : H113°/D144°/V84°(2.8mm)

H98°/D124°/V73°(3.2mm)

H82°/105°/V60°(3.6mm)

H52°/D65°/V39°(6mm)

Shutter Time: 1/100000s∼1s

IR Distance: Up to 30m

Day & Night : ICR Filter Auto Switch

Video

Max. Image Resolution : 2592×1944

Primary Stream : 20fps@(2592×1944), 30fps(1920x1080, 1280×960, 1280×720, 704×576)

Secondary Stream : 30fps@(704x576, 640x480, 640x360, 352x288, 320x240, 320x192, 320x176)

Tertiary Stream : 30fps@(1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240, 320x192, 320x176)

Video Compression : H.265+/H.265(HEVC)/H.264+/H.264/MJPEG

Video Bit Rate: 16Kbps∼16Mbps (CBR/VBR adjustable)

Image Settings : Saturation/Brightness/Contrast/Sharpness

Network

Ethernet : 1*RJ45 10M/100M Ethernet Port

Network Storage : NAS(Support NFS, SMB/CIFS)

Network Protocols : IPv4/IPv6, TCP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, UPnP, SIP, SNMP, PPPoE, VLAN, 802.1, QoS, IGMP, ICMP, SSL

System

SIP/VoIP Support : Yes, Voice & Video-over-IP
